Grundfos 99350626 - CRI 5-3 F-FGJ-A-F-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 99350626

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 99350626 - CRI 5-3 F-FGJ-A-F-HQQE is a vertical multistage centrifugal pump used in industrial and commercial systems where high-pressure, compact inline pumping is required. Grundfos manufactures this model for service technicians and plant operators needing reliable replacement units.

Key features

  • Designed for multistage centrifugal pumping in vertical, inline configurations
  • Suitable for high-pressure service and general industrial applications
  • Provides consistent pressure boost and stable flow for process systems

Applications

Typical uses include water supply and transfer, pressure boosting, HVAC and boiler feed support, and other industrial process services where a vertical multistage centrifugal pump is specified.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 99350626

EAN 5713827676802
Approvals CURUS
Built-in motor protection NONE
Code for rubber F
Code for shaft seal HQQE
Connect code FGJ
Connection PN 25
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Enclosure class (IEC 34-5) 55 Dust/Jetting
Flange rating inlet 300 lb
Flange size for motor 56C
Frequency converter NONE
Gross weight 95.5 lb
IE Efficiency class NEMA Premium / IE3 60Hz
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) B
Liquid temperature range 14 .. 356 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 6
Max pressure at stated temp 363 psi / 356 °F
Maximum ambient temperature 104 °F
Maximum head 96.13 ft
Maximum operating pressure 25 bar
Model A
Motor 56C
Motor standard NEMA
Motor type BALDOR
Net weight 84.5 lb
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 0.75 kW
Pressure rating for connection PN 25
Pressure sensor N
Pump 0.75 kW
Pump speed on which pump data are based 3484 rpm
Pump version F
Pumped liquid Water
Rated flow 30.4 US gpm
Rated head 65.29 ft
Rated power - P2 0.75 kW
Rated speed 3450 rpm
Rated voltage 3 x 230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber F
Selected liquid temperature 68 °F
Service factor 1.25
Size of inlet connection DN 25/32
Size of outlet connection DN 25/32
Stages 3
Standard NEMA
Type BALDOR
Type of connection DIN / ANSI / JIS
Version F

Motor Curves

Dimensional Drawing

DWiring Diagram
