EAN
        5700396916477















        Applications
        Industrial applications








            Actual impeller diameter

              4.13 in










            Approvals

              CURUS








            Approvals for drinking water

              NSF/ANSI 61








            Bearing 1

              SIC








            Built-in motor protection

              NONE








            Code for rubber

              E








            Code for shaft seal

              HQQE








            Connect code

              P








            Connection

              PJE








            Connection 2

              DN 50








            Connection 3

              DN 50








            Connection 4

              PN 50








            Cooling

              TEFC








            Curve tolerance

              ISO9906:2012 3B








            Density

              62.29 lb/ft³








            Diameter

              4.13 in












            DOE Pump Energy Index CL

              0.91










            Enclosure class (IEC 34-5)

              55  Dust/Jetting








            Eta 1/1

              86.5-86.5%








            Flange size for motor

              182TC








            Frequency

              60 HZ








            Frequency converter

              NONE








            Full load SF current

              9,60-9,20/4,60 A








            Gross weight




              132.0 lb








            IE Eff. Class

              NEMA Premium / IE3 60Hz








            IE efficiency

              classNEMA Premium / IE3 60Hz








            IE Efficiency class

              NEMA Premium / IE3 60Hz








            Impeller

              Stainless steel








            Impellers

              1








            Insulation

              F








            Insulation class (IEC 85)

              F










            Liquid max temp

              120°C








            Liquid temperature range

              -4 .. 248 °F








            Low NPSH

              N








            Material code

              A








            Material Pricing Group

              6








            Max pressure at stated temp

              232 psi / 250 °F








            Maximum ambient temperature

              140 °F








            Maximum head

              66.93 ft








            Maximum operating pressure

              232.06 psi








            Maximum permissible operating pressure

              16bar








            Model

              A








            Motor

              182TC










            Motor efficiency at 1/2 load

              91.4-90.1 %








            Motor efficiency at 3/4 load

              91.1-90.9 %








            Motor efficiency at full load 1

              86.5-86.5 %








            Motor protec

              NONE








            Motor standard

              NEMA








            Motor type

              90HA








            n rpm

              3500-3520rpm








            Net weight




              115.0 lb








            Number of poles

              2








            Number of reduced-diameter impellers

              0








            P2 HP

              3 HP








            P2 kW

              2.2kW








            Phase

              3








            Power (P2) required by pump

              3 HP








            Power factor 1

              0.85-0.82








            Pressure rating

              PN 50








            Pressure rating for connection

              PN 50








            Product family

              CRI 20








            Pump

              3 HP








            Pump housing

              Stainless steel








            Pump inlet

              DN 50








            Pump outlet

              DN 50








            Pump version

              A








            Pumped liquid

              Water








            Rated current

              8,50-8,20/4,10 A








            Rated flow

              111 US gpm








            Rated flow 2

              111 US gpm








            Rated head

              49.54 ft








            Rated head 2

              49.54 ft








            Rated power - P2

              3 HP








            Rated speed

              3500-3520 rpm








            Rated voltage

              3 x 208-230YY/460Y V








            Real Time

              Delivery date to be confirmed on Sales Order Update with real time availability and Net price








            Rubber

              E








            Selected liquid temperature

              68 °F








            Service factor

              1.15








            Shaft seal

              HQQE








            Size of inlet connection

              DN 50








            Size of outlet connection

              DN 50








            Stages

              2








            Standard

              NEMA








            Starting current

              850-970 %








            Type

              90HA








            Type of connection

              PJE








            Version

              A
