Grundfos 96881592 - CRI 15-12 F-FGJ-A-F-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 96881592

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos CRI 15-12 F-FGJ-A-F-HQQE is a vertical multistage centrifugal pump designed for industrial and commercial high-pressure inline systems, suited for service technicians and plant operators.

Key features

  • Engineered by Grundfos for industrial applications and service replacement
  • Vertical, multistage inline design for high-pressure operation
  • Delivers reliable pressure boosting and efficient multistage performance for continuous duty

Applications

Typical uses include boiler feed, pressure boosting, process water transfer, closed-loop systems, and other high-pressure inline pumping tasks.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 96881592

EAN 5700312596653
Actual impeller diameter 4.13 in
Approvals CURUS
Built-in motor protection NONE
Code for rubber F
Code for shaft seal HQQE
Connect code FGJ
Connection PN 25
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Diameter 4.13 in
DOE Pump Energy Index CL 0.91
Enclosure class (IEC 34-5) IP54
Flange rating inlet 300 lb
Flange size for motor 284TC
Frequency converter NONE
Gross weight 624.0 lb
IE efficiency IE3 93%
IE Efficiency class IE3 / NEMA Premium
Impeller Stainless steel
Impellers 0
Insulation class (IEC 85) F
Liquid temperature range 14 .. 356 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 30
Max pressure at stated temp 363 psi / 356 °F
Maximum ambient temperature 104 °F
Maximum head 800.6 ft
Maximum operating pressure 25 bar
Model A
Motor 284TC
Motor efficiency at full load 1 0.93
Motor standard NEMA
Motor type BALDOR
Net weight 472.0 lb
Number of poles 2
Number of reduced-diameter impellers 0
Power (P2) required by pump 18.5 kW
Pressure rating for connection PN 25
Pressure sensor N
Pump 18.5 kW
Pump speed on which pump data are based 3521 rpm
Pump version F
Pumped liquid Water
Rated current 56/28 A
Rated flow 90.3 US gpm
Rated head 644.4 ft
Rated power - P2 18.5 kW
Rated speed 3530 rpm
Rated voltage 3 x 230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber F
Selected liquid temperature 68 °F
Service factor 1.15
Size of inlet connection DN 50
Size of outlet connection DN 50
Stages 12
Standard NEMA
Type BALDOR
Type of connection DIN / ANSI / JIS
Version F

Motor Curves

Dimensional Drawing

DWiring Diagram
