Grundfos 99387101 - CR 45-2-2 FH-GB-A-E-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 99387101

Price:
Sale price$34,920.83
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 99387101 - CR 45-2-2 FH-GB-A-E-HQQE is a vertical multistage centrifugal pump designed for industrial and commercial fluid handling where compact, high-pressure inline performance is required. Professionals servicing process, HVAC, and water systems use this replacement unit.

Key features

  • Built for industrial applications with multistage centrifugal design for steady pressure delivery
  • Configured for vertical, in-line mounting and high-pressure service as indicated by product tags
  • Provides reliable, space-saving operation that minimizes downtime and simplifies maintenance

Applications

Suitable for high-pressure boosting, boiler feed, process circulation, and other vertical inline multistage centrifugal duties in commercial and industrial settings.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 99387101

EAN 5713828284754
Approvals CURUS
Bearing 1 Graflon
Built-in motor protection NONE
Code for rubber E
Code for shaft seal HQQE
Connect code GB
Connection PN 40
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Flange rating inlet 300 lb
Flange size for motor 254TC
Frequency converter NONE
Gross weight 501.0 lb
IE Efficiency class NEMA Premium / IE3 60Hz
Impeller Stainless steel
Impellers 2
Insulation class (IEC 85) F
Liquid temperature range -22 .. 302 °F
Low NPSH N
Mains frequency 60 Hz
Material code A
Material Pricing Group 6
Max pressure at stated temp 363 psi / 302 °F
Maximum ambient temperature 104 °F
Maximum head 185.4 ft
Maximum operating pressure 25 bar
Model B
Motor 254TC
Motor efficiency at full load 1 0.91
Motor standard NEMA
Motor type BALDOR
Net weight 382.0 lb
Number of poles 2
Number of reduced-diameter impellers 2
Power (P2) required by pump 11 kW
Pressure rating for connection PN 40
Pressure sensor N
Pump 11 kW
Pump speed on which pump data are based 3444 rpm
Pump version FH
Pumped liquid Water
Rated current 38
Rated flow 231 US gpm
Rated head 146 ft
Rated power - P2 11 kW
Rated speed 3510 rpm
Rated voltage 3 x 208-230/460 V
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Service factor 1.15
Size of inlet connection 3 inch
Size of outlet connection 1 1/2 inch
Stages 2
Standard NEMA
Support bearing Graflon
Type BALDOR
Type of connection GB
Version FH

Motor Curves

Dimensional Drawing

DWiring Diagram
