Grundfos 97534627 - CR 32-7 H-G05-A-E-HQQE | Vertical | Multistage | Centrifugal

Save $6,548.40
GRUNDFOSSKU: 97534627

Price:
Sale price$8,751.60 Regular price$15,300.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 97534627 - CR 32-7 H-G05-A-E-HQQE Vertical Multistage Centrifugal Pump

The Grundfos 97534627 - CR 32-7 H-G05-A-E-HQQE is a high-performance vertical multistage centrifugal pump designed for a variety of industrial applications. Manufactured by Grundfos, a leader in pump technology, this model ensures reliability and efficiency in fluid handling.

This pump is part of the CR series, known for its robust construction and versatility. It is ideal for boosting pressure in water supply systems, HVAC applications, and other industrial processes. The CR 32-7 model features a compact design, making it suitable for installations with limited space.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility.

For more information on specifications and applications, feel free to reach out to our knowledgeable team. We are here to help you find the perfect solution for your pumping needs.

Approvals on nameplate CE,NSF/ANSI 61
Bearing 1 Graflon
Code for rubber E
Code for shaft seal HQQE
Connect code G05
Connection PN 40
Curve tolerance ISO9906:2012 3B
Flange rating inlet 300 lb
Flange size for motor 284TC
Frequency converter NONE
Gross weight 346.0 lb
Impeller Stainless steel
Impellers 0
Liquid max temp 248°F
Liquid temperature range -22 .. 248 °F
Low NPSH N
Material code A
Maximum head 625.4 ft
Maximum operating pressure 435.11 psi
Model B
Motor 284TC
Motor standard NEMA
n rpm 3541rpm
Net weight 185.0 lb
Number of reduced-diameter impellers 0
Pressure rating for connection PN 40
Pressure sensor N
Pump Y
Pump version H
Rated flow 136 US gpm
Rated head 504.3 ft
Rubber E
Sales region USA
Shaft Product name:CR 32-7 H-G05-A-E-HQQE
Shaft seal HQQE
Stages 7
Standard NEMA
Support bearing Graflon
Version H

Motor Curves

Dimensional Drawing
