Grundfos 97534558 - CR 32-6-2 H-GA-A-E-HQQE | Vertical | Multistage | Centrifugal

Save $6,077.60
GRUNDFOSSKU: 97534558

Price:
Sale price$8,122.40 Regular price$14,200.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 97534558 - CR 32-6-2 H-GA-A-E-HQQE is a high-performance vertical multistage centrifugal pump designed for a variety of industrial applications. Manufactured by the renowned vendor Grundfos, this pump is engineered for efficiency and reliability, making it an ideal choice for boosting water pressure and handling various fluid transfer tasks.

This model is part of the CR series, known for its robust construction and versatility. It is categorized under Horizontal Multistage and Centrifugal Pumps, ensuring optimal performance in demanding environments. The CR 32-6-2 H-GA-A-E-HQQE is suitable for applications requiring consistent flow rates and high pressure.

At Pump-Stop.com, we pride ourselves on being the preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches to ensure compatibility.

For more information on specifications and applications, feel free to reach out to our knowledgeable team. We are here to help you find the perfect solution for your pumping needs.

Approvals on nameplate CE,NSF/ANSI 61
Bearing 1 Graflon
Code for rubber E
Code for shaft seal HQQE
Connect code GA
Connection PN 40
Curve tolerance ISO9906:2012 3B
Flange rating inlet 300 lb
Flange size for motor 284TC
Frequency converter NONE
Gross weight 270.0 lb
Impeller Stainless steel
Impellers 2
Liquid max temp 248°F
Liquid temperature range -22 .. 248 °F
Low NPSH N
Material code A
Maximum head 491.5 ft
Maximum operating pressure 435.11 psi
Model B
Motor 284TC
Motor standard NEMA
n rpm 3521rpm
Net weight 171.0 lb
Number of reduced-diameter impellers 2
Pressure rating for connection PN 40
Pressure sensor N
Pump Y
Pump version H
Rated flow 136 US gpm
Rated head 404.2 ft
Rubber E
Sales region USA
Shaft Product name:CR 32-6-2 H-GA-A-E-HQQE
Shaft seal HQQE
Stages 6
Standard NEMA
Support bearing Graflon
Version H

Motor Curves

Dimensional Drawing
