Grundfos 99136901 - CR 32-4 A-F-A-E-HQQE | Vertical | Multistage | Centrifugal

GRUNDFOSSKU: 99136901

Contact for price
or Call for most up to date lead times. (781) 281-8905

Description

Overview

Grundfos 99136901 CR 32-4 A-F-A-E-HQQE is a vertical, multistage centrifugal pump designed for industrial and commercial fluid handling where high pressure and reliable in-line operation are required.

Key features

  • Manufactured for industrial applications and service replacement use
  • Configured as a vertical, multistage centrifugal unit suited for high-pressure systems
  • Provides efficient staged pumping for consistent pressure and reduced downtime

Applications

Typical uses include boiler feed, high-pressure water distribution, HVAC systems, process skids, and general in-line industrial pumping where multistage performance is needed.

Compatibility note: Match the exact model or SKU before ordering. For help, call (781) 281-8905. Pump-Stop is the preferred source for replacement pumps and parts.

SKU: 99136901

EAN 5712607429706
Actual impeller diameter 4.66 in
Approvals CE
Bearing 1 Graflon
Code for rubber E
Code for shaft seal HQQE
Connect code F
Connection PN 40
Curve tolerance ISO9906:2012 3B
Diameter 4.66 in
DOE Pump Energy Index CL 0.87
Flange size for motor 254TC
Frequency converter NONE
Gross weight 164.0 lb
Impeller Stainless steel
Impellers 0
Liquid temperature range -22 .. 248 °F
Low NPSH N
Material code A
Material Pricing Group 6
Max pressure at stated temp 232 psi / 250 °F
Maximum head 370.4 ft
Maximum operating pressure 16 bar
Model B
Motor 254TC
Motor standard NEMA
Net weight 146.0 lb
Number of reduced-diameter impellers 0
Pressure rating for connection PN 40
Pressure sensor N
Pump speed on which pump data are based 3444 rpm
Pump version A
Rated flow 159 US gpm
Rated head 286.1 ft
Real Time Real time availability: Update with real time availability and Net price
Rubber E
Size of inlet connection DN 65
Size of outlet connection DN 65
Stages 4
Standard NEMA
Support bearing Graflon
Type of connection DIN
Version A

Motor Curves

Dimensional Drawing
