Grundfos 97669019 - CR 32-3-2 H-GB-A-V-HQQV | Vertical | Multistage | Centrifugal

Save $3,732.59
GRUNDFOSSKU: 97669019

Price:
Sale price$4,988.41 Regular price$8,721.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 97669019 - CR 32-3-2 H-GB-A-V-HQQV Vertical Multistage Centrifugal Pump

The Grundfos 97669019 - CR 32-3-2 H-GB-A-V-HQQV is a high-performance vertical multistage centrifugal pump designed for a variety of industrial applications. Manufactured by the renowned vendor Grundfos, this pump is engineered to deliver reliable and efficient performance in demanding environments.

With its robust construction and advanced design, the CR 32-3-2 H-GB-A-V-HQQV model is ideal for boosting pressure and transporting fluids in various systems. This pump is part of the CR series, known for its versatility and adaptability, making it suitable for both horizontal and vertical installations.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches to ensure compatibility.

For more information on specifications and applications, feel free to reach out to our knowledgeable team. We are here to help you find the perfect solution for your pumping needs.

Approvals on nameplate CE
Bearing 1 Graflon
Code for rubber V
Code for shaft seal HQQV
Connect code GB
Connection PN 16
Curve tolerance ISO9906:2012 3B
Flange rating inlet 150 lb
Flange size for motor 213TC
Frequency converter NONE
Gross weight 265.0 lb
Impeller Stainless steel
Impellers 2
Liquid max temp 194°F
Liquid temperature range -4 .. 194 °F
Low NPSH N
Material code A
Maximum head 230 ft
Maximum operating pressure 232.06 psi
Model B
Motor 213TC
Motor standard NEMA
n rpm 3470rpm
Net weight 166.0 lb
Number of reduced-diameter impellers 2
Pressure rating for connection PN 16
Pressure sensor N
Pump Y
Pump version H
Rated flow 132 US gpm
Rated head 197.2 ft
Rubber V
Sales region USA
Shaft Product name:CR 32-3-2 H-GB-A-V-HQQV
Shaft seal HQQV
Stages 3
Standard NEMA
Support bearing Graflon
Version H

Motor Curves

Dimensional Drawing
