Grundfos 98160018 - CR 1S-8 A-FGJ-A-E-HQQE

Save $1,278.24
GRUNDFOSSKU: 98160018

Price:
Sale price$1,384.76 Regular price$2,663.00
Delivery date to be confirmed on Sales Order
Chat or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 98160018 - CR 1S-8 A-FGJ-A-E-HQQE This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.

EAN 5711494593651
Material Pricing Group 6
Motor efficiency at full load 1 73.8-73.8 %
IE Efficiency class IE3
Code for rubber E
Maximum ambient temperature 140 °F
Material code A
Density 62.29 lb/ft³
Max pressure at stated temp 363 psi / 250 °F
Maximum operating pressure 25 bar
Size of inlet connection DN 25/32
Power factor 1 0.80-0.70
Selected liquid temperature 68 °F
Type of connection DIN / ANSI / JIS
Rated voltage 3 x 220-240D/380-415Y V
Flange size for motor FT85
Pumped liquid Water
Size of outlet connection DN 25/32
Starting current 490-530 %
Connect code FGJ
Liquid temperature range -4 .. 248 °F
Mains frequency 50 Hz
Insulation class (IEC 85) F
Motor efficiency at 1/2 load 75.5-71.5 %
Built-in motor protection NONE
Net weight 55.2 lb
Number of poles 2
Rated speed 2850-2880 rpm
Gross weight 61.3 lb
Rated power - P2 0.37 kW
Enclosure class (IEC 34-5) 55 Dust/Jetting
Power (P2) required by pump 0.37 kW
Pressure rating for connection PN 25
Motor efficiency at 3/4 load 79.0-76.5 %
Rated current 1.74/1.00 A
Frequency converter NONE
Motor type 71AB
Pressure sensor N
Pump speed on which pump data are based 2873 rpm
Stages 8
Rated flow 3.96 US gpm
Model A
Version A
Motor FT85
Rubber E
Maximum head 155.8 ft
Motor standard IEC
Rated head 106.6 ft
Type 71AB
Curve tolerance ISO9906:2012 3B
Impellers 0
Connection PN 25
Impeller Stainless steel
Code for shaft seal HQQE
Number of reduced-diameter impellers 0
Flange rating inlet 250 lb
Pump 0.37 kW
Low NPSH N
Standard IEC
Pump version A
