Grundfos 99495676 - CR 15-2 A-B-A-E-HQQE | Multistage | Centrifugal | Vertical | Inline

GRUNDFOSSKU: 99495676

Contact for price
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

CR 15-2 A-B-A-E-HQQE Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via oval flanges with internal NPT threads.

EAN 5713830034170
Code for rubber E
Code for shaft seal HQQE
Connect code B
Connection Oval / NPT(F)
Curve tolerance ISO9906:2012 3B
Density 62.29 lb/ft³
Frequency converter NONE
Gross weight 117.0 lb
Impeller Stainless steel
Impellers 0
Liquid temperature range -4 .. 194 °F
Low NPSH N
Material code A
Material Pricing Group 6
Max pressure at stated temp 232 psi / 194 °F
Maximum head 33.79 ft
Maximum operating pressure 16 bar
Model A
Motor standard NEMA
Net weight 99.2 lb
Number of reduced-diameter impellers 0
Power (P2) required by pump 0.37 kW
Pressure sensor N
Pump 0.37 kW
Pump speed on which pump data are based 1739 rpm
Pump version A
Pumped liquid Water
Rated flow 45.3 US gpm
Rated head 25.26 ft
Real Time Delivery date to be confirmed on Sales Order  Update with real time availability and Net price
Rubber E
Selected liquid temperature 68 °F
Stages 2
Standard NEMA
Type of connection Oval / NPT(F)
Version A

Motor Curves

Dimensional Drawing
