Grundfos 97658071 - CR 10-3 H-GA-A-V-HQQV | Vertical | Multistage | Centrifugal

Save $2,648.46
GRUNDFOSSKU: 97658071

Price:
Sale price$3,539.54 Regular price$6,188.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Grundfos 97658071 - CR 10-3 H-GA-A-V-HQQV Vertical Multistage Centrifugal Pump

The Grundfos 97658071 - CR 10-3 H-GA-A-V-HQQV is a high-performance vertical multistage centrifugal pump designed for a variety of industrial applications. Engineered by Grundfos, a leader in pump technology, this model ensures efficient fluid transfer and reliable operation in demanding environments.

This pump is part of the CR series, known for its versatility and durability. It is ideal for boosting pressure in water supply systems, HVAC applications, and other industrial processes. The CR 10-3 model features a robust construction that allows it to handle a wide range of fluids, making it a preferred choice for many professionals.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility.

For more information on specifications and applications, feel free to reach out to our knowledgeable team. We are here to help you find the perfect solution for your pumping needs.

Approvals on nameplate CURUS
Bearing 1 SIC
Built-in motor protection NONE
Code for rubber V
Code for shaft seal HQQV
Connect code GA
Connection PN 16
Cooling TEFC
Curve tolerance ISO9906:2012 3B
Enclosure class (IEC 34-5) 55 Dust/Jetting
Flange rating inlet 150 lb
Flange size for motor 182TC
Frequency 60 Hz
Frequency converter NONE
Gross weight 271.0 lb
IE Eff. Class NEMA Premium / IE3 60Hz
IE efficiency Product name:CR 10-3 H-GA-A-V-HQQV
IE Efficiency class NEMA Premium / IE3 60Hz
Impeller Stainless steel
Impellers 0
Insulation F
Insulation class (IEC 85) F
IP Class 55 Dust/Jetting
Liquid max temp 194°F
Liquid temperature range -4 .. 194 °F
Low NPSH N
Material code A
Maximum ambient temperature 140 °F
Maximum head 139.4 ft
Maximum operating pressure 232.06 psi
Model A
Motor 182TC
Motor efficiency at 1/2 load 91.4-90.1 %
Motor efficiency at 3/4 load 91.1-90.9 %
Motor efficiency at full load 1 86.5-86.5 %
Motor standard NEMA
Motor type 90HA
n rpm F
Net weight 170.0 lb
Number of poles 2
Number of reduced-diameter impellers 0
P2 kW 3 HP
Phase 3
Power (P2) required by pump 3 HP
Power factor 1 0.85-0.82
Pressure rating for connection PN 16
Pressure sensor N
Pump 3 HP
Pump version H
Rated current 8,50-8,20/4,10 A
Rated flow 52.8 US gpm
Rated head 112.2 ft
Rated power - P2 3 HP
Rated speed 3500-3520 rpm
Rated voltage 3 x 208-230YY/460Y V
Rubber V
Sales region USA
Service factor 1.15
Shaft Product name:CR 10-3 H-GA-A-V-HQQV
Shaft seal HQQV
Stages 3
Standard NEMA
Starting current 850-970 %
Type 90HA
Version H

Motor Curves

Dimensional Drawing

DWiring Diagram
