Description
Grundfos 99923590 - CM 25-4 X-R-G-E-AQQE F-A-A-N This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
EAN
5715114208734
Material Pricing Group
35
IE Efficiency class
IE3
Code for rubber
E
Material code
G
Density
62.29 lb/ft³
Max pressure at stated temp
232 psi / 194 °F
Maximum operating pressure
16 bar
Size of inlet connection
2 inch
Selected liquid temperature
68 °F
Type of connection
Rp
Rated voltage
3 x 220-240D/380-415Y V
Pumped liquid
Water
Size of outlet connection
2 inch
Starting current
780-910 %
Connect code
R
Liquid temperature range
-22 .. 248 °F
Mains frequency
50 Hz
Insulation class (IEC 85)
F
Built-in motor protection
NONE
Net weight
110.0 lb
Rated speed
2910-2920 rpm
Gross weight
116.0 lb
Rated power - P2
7.5 kW
Enclosure class (IEC 34-5)
IP55
Rated current
25
Service factor
1
Minimum efficiency index, MEI ≥
0.41
Frequency converter
NONE
Range of ambient temperature
-4 .. 131 °F
Terminal box position
12
Pump speed on which pump data are based
2900 rpm
Approvals
CE
Rated flow
96.9 US gpm
Model
A
Version
X
Rubber
E
Size
132SB
Housing
Stainless steel
Approvals for drinking water
WRAS
Motor standard
IEC
Rated head
205.2 ft
Curve tolerance
ISO9906:2012 3B
Impellers
4
Suitable for 50/60 Hz
N
Connection
2 inch
Impeller
Stainless steel
Code for shaft seal
AQQE
Pump housing
Stainless steel
Cable included (Yes/No)
N
Frame size
132SB
Standard
IEC
Pump version
X
Motor Curves
