Description
Grundfos 99561575 - CM 10-2 A-S-I-V-AQQV J-A-A-N This product is manufactured by Grundfos for various industrial applications. For more information on specifications and applications please chat or call our team.
EAN
5713831070627
Material Pricing Group
35
IE Efficiency class
IE3
Code for rubber
V
Material code
I
Density
62.29 lb/ft³
Max pressure at stated temp
232 psi / 194 °F
Maximum operating pressure
16 bar
Size of inlet connection
1 1/2 inch
Selected liquid temperature
68 °F
Type of connection
NPT(F)
Rated voltage
3 x 380-415 V V
Pumped liquid
Water
Size of outlet connection
1 1/2 inch
Starting current
1100-1150 %
Connect code
S
Liquid temperature range
-4 .. 194 °F
Mains frequency
50 Hz
Insulation class (IEC 85)
F
Built-in motor protection
NONE
Net weight
64.5 lb
Rated speed
2960-2970 rpm
Gross weight
70.0 lb
Rated power - P2
1.27 kW
Enclosure class (IEC 34-5)
IP55
Rated current
3.30-3.60 A
Service factor
1
Minimum efficiency index, MEI ≥
0.52
Frequency converter
NONE
Range of ambient temperature
-4 .. 131 °F
Terminal box position
12
Pump speed on which pump data are based
2900 rpm
Approvals
CE
Rated flow
52.8 US gpm
Model
A
Version
A
Rubber
V
Size
90HA
Housing
Stainless steel
Approvals for drinking water
WRAS
Motor standard
NEMA
Rated head
116.3 ft
Curve tolerance
ISO9906:2012 3B
Impellers
2
Suitable for 50/60 Hz
Y
Connection
1 1/2 inch
Impeller
Stainless steel
Code for shaft seal
AQQV
Pump housing
Stainless steel
Cable included (Yes/No)
N
Frame size
90HA
Standard
NEMA
Pump version
A
