Barnes 100835 - Pump, BP314VFBR, 115, Vt Fl

This item ships free!
BarnesSKU: 100835

Price:
Sale price$6,012.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Crane Pumps & Systems — Barnes Brand · Piqua, Ohio · Est. 1856
Model PUMP · BP Effluent Pump · Barnes
2″ DischargeUp to 70 GPMUp to 30 TDH Head1/3 HP Range

The Barnes PUMP, 314V pump, bp314vfbr, 115, vt fl. Effluent pumps are designed for handling dirty water in typical septic tank and effluent applications. High temperature models are available. Barnes effluent pumps are designed to handle most low and high head effluent applications. Series capacity up to 70 GPM at 30 TDH head.

HP Range
1/3
Max Flow
70 GPM
Max Head
30 TDH
Discharge
2″
Speed
1750
Voltage
314V
Submersible Construction
Cast iron — rated for continuous submerged operation in residential and commercial systems
Crane Pumps & Systems
A Crane Co. company — 165+ years of pump engineering. Barnes, Burks, Deming, and Weinman under one roof in Piqua, Ohio
Wide HP Range
1/3 HP available
Expert Support
Technical sizing and compatibility help — call (781) 281-8905 or chat
Why This Product

Submersible Construction — Continuous Duty

Cast iron construction rated for continuous submerged operation. Oil-filled motor dissipates heat into surrounding fluid — enabling 24/7 duty cycle operation without overheating.

2" Solids Handling

2" spherical solids passage allows tissue, personal care products, and residential sewage materials to pass without clogging — the minimum specification for residential sewage service under most plumbing codes.

Thermal Overload Protection — Auto Reset

Automatic thermal overload shuts the motor down on temperature exceedance and resets after cooling. Prevents permanent motor damage from blocked discharge, run-dry, or overload conditions.

Multiple Switch Configurations

Available with no switch (manual), vertical float, wide-angle float, and piggyback switch types — select the configuration matched to your basin geometry and automatic operation requirements.

Cast Iron Volute and Impeller

Cast iron construction provides wear resistance required for sewage service. Cast iron is the industry standard material for residential and commercial sewage pump applications.

Crane Pumps & Systems Quality

Barnes effluent and sewage pumps are manufactured by Crane Pumps & Systems in Piqua, Ohio — backed by 165 years of pump engineering and a national service network.

Technical Specifications
Model Number 100835
Series BP Effluent Pump
Brand Barnes
Horsepower 1/3
Voltage 314V
Series HP Range 1/3
Max Flow Rate 70 GPM
Max Head 30 TDH
Discharge Size 2″
Speed 1750
Key Features
Cast iron Construction
Stainless Steel Shaft
Ball Bearing Construction
Quick Connect Cords on Select Models
CSA Listed
Available in all bronze construction
Available Options
High Temperature Models
Additional Cable lengths
Upgraded Seal Materials
Typical Applications
Septic Systems
Industrial wastewater
Reclaimed water systems
Greywater
Important Notices
Fluid compatibility For use with liquids compatible with pump component materials. Verify chemical, temperature, and pressure compatibility before use.
Electrical Requires a properly sized grounded branch circuit and motor starter with correctly rated thermal overload protection.
Operating limits Do not exceed series pressure, temperature, and speed ratings. Operation outside rated limits causes premature seal and bearing failure.
Service Disconnect and lockout/tagout power before any service. Allow pump to cool before handling after operation.
Available Documentation
✓ Product Specification Sheet — BP Effluent Pump
✓ Installation, Operation & Maintenance Manual (IOM)
✓ Repair Parts Manual
Need the spec sheet, IOM, or parts list? Contact PumpStop and we'll send it over.
Before You OrderConfirm HP, voltage, phase, and enclosure type are correct for your installation. All models in the BP Effluent Pump share casing dimensions and spare parts — motor configuration is the only difference between models. For sizing guidance, chat or call (781) 281-8905.
Supplier Part Number 100835
