UPC
781568199947
Supplier Part Number
ZDM3774T-5
Category
AC Motors
Subcategory
AC Inverter/Vector Duty Motors
Product Family
General Purpose
Agency Approvals
UR, CSA
Ambient Temperature
40 °C
Approximate Weight (lbs)
231.0
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
Rigid
Bearing Grease Type
Polyrex EM (-20F +300F)
Blower
BLOWER
Catalog Number
ZDM3774T-5
Current @ Voltage
10.000 A @ 575.0 V
Design Code
A
Drip Cover
No Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
92.4 %
Electrically Isolated Bearing
Not Electrically Isolated
Enclosure
TEBC
Feedback Device
ENCODER
Frame
215TC
Frame Material
Cast Iron
Frequency
60.00 Hz
Front Face Code
Encoder/Feedback Device
Front Shaft Indicator
None
Haz Area Class and Group
NONE
Haz Area Division
Not Applicable
Heater Indicator
No Heater
High Voltage Full Load Amps
10.0 a
Insulation Class
H
Inverter Code
Inverter Duty
KVA Code
H
Lifting Lugs
Standard Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Max Speed
4000 rpm
Motor Lead Exit
Ko Box
Motor Lead Quantity/Wire Size
3 @ 14 AWG
Motor Lead Termination
Flying Leads
Motor Letter Type
Three Phase
Motor Standards
NEMA
Motor Type
0748M
Mounting Arrangement
F1
Number of Poles
4
Output
10.000 hp
Output @ Frequency
10.000 HP @ 60 HZ
Overall Length
25.58 IN
Phase
3
Power Factor
81
Pulley End Bearing Type
Ball
Pulley Face Code
C-Face
Pulley Shaft Indicator
Standard
Rodent Screen
None
RoHS Status
ROHS NON-COMPLIANT
Service Factor
1
Shaft Diameter
1.375 IN
Shaft Extension Location
Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator
No Slinger
Speed
1760 rpm
Speed Code
Single Speed
Starting Method
Direct on line
Synchronous Speed
1,800 rpm
Synchronous Speed @ Frequency
1800 RPM @ 60 HZ
Thermal Device - Bearing
None
Thermal Device - Winding
Normally Closed Thermostat
Vibration Sensor Indicator
No Vibration Sensor
Voltage
575 V
Voltage @ Frequency
575.0 V @ 60 HZ
Winding Thermal 1
None
Winding Thermal 2
None
