UPC
781568820698
Supplier Part Number
VJPFPM2546T-2/4
Category
AC Motors
Subcategory
Fire Pump
Product Family
General Purpose
Agency Approvals
CULUS, CSA EEV
Ambient Temperature
40 °C
Approximate Weight (lbs)
385.0
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
No Mounting
Bearing Grease Type
Polyrex EM (-20F +300F)
Blower
None
Catalog Number
VJPFPM2546T-2/4
Current @ Voltage
156.000 A @ 200.0 V, 78.000 A @ 400.0 V
Design Code
B
Drip Cover
Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
93.0 %
Electrically Isolated Bearing
Not Electrically Isolated
Enclosure
ODP
Feedback Device
NO FEEDBACK
Frame
326JP
Frame Material
Steel
Frequency
60.00 Hz
Front Face Code
Drip Cover Mounting
Front Shaft Indicator
None
Heater Indicator
No Heater
High Voltage Full Load Amps
78.0 a
Insulation Class
F
Inverter Code
Not Inverter
KVA Code
G
Lifting Lugs
Vertical Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Motor Lead Exit
Ko Box
Motor Lead Quantity/Wire Size
12 @ 8 AWG
Motor Lead Termination
Flying Leads
Motor Letter Type
Three Phase
Motor Standards
NEMA
Motor Type
4062M
Mounting Arrangement
F1
Number of Poles
2
Output
60.000 hp
Output @ Frequency
60.000 HP @ 60 HZ
Overall Length
32.21 IN
Phase
3
Power Factor
89
Pulley End Bearing Type
Ball
Pulley Face Code
C-Face
Pulley Shaft Indicator
Tapped & Key
Rodent Screen
Included
Service Factor
1.15
Shaft Diameter
1.750 IN
Shaft Extension Location
Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator
Shaft Slinger
Speed
3520 rpm
Speed Code
Single Speed
Starting Method
Wye Start - Delta Run
Synchronous Speed
3,600 rpm
Synchronous Speed @ Frequency
3600 RPM @ 60 HZ
Thermal Device - Bearing
None
Thermal Device - Winding
None
Vibration Sensor Indicator
No Vibration Sensor
Voltage
200 V, 400 V
Voltage @ Frequency
200.0 V @ 60 HZ, 400.0 V @ 60 HZ
Winding Thermal 1
None
Winding Thermal 2
None
