UPC
781568817100
Supplier Part Number
VJPFPM2535T
Category
AC Motors
Subcategory
Fire Pump
Product Family
Fire Pump Motor
Agency Approvals
CSA EEV, CULUS
Ambient Temperature
40 °C
Approximate Weight (lbs)
375.0
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
No Mounting
Bearing Grease Type
Polyrex EM (-20F +300F)
Blower
None
Catalog Number
VJPFPM2535T
Current @ Voltage
72.000 A @ 230.0 V, 72.000 A @ 190.0 V, 36.000 A @ 460.0 V, 36.000 A @ 380.0 V
Design Code
B
Drip Cover
Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
92.4 %
Electrically Isolated Bearing
Not Electrically Isolated
Enclosure
ODP
Feedback Device
NO FEEDBACK
Frame
286JP
Frame Material
Steel
Frequency
50.00 Hz, 60.00 Hz
Front Face Code
Drip Cover Mounting
Front Shaft Indicator
None
Heater Indicator
No Heater
High Voltage Full Load Amps
36.0 a
Insulation Class
F
Inverter Code
Not Inverter
IP Rating
NONE
KVA Code
G
Lifting Lugs
Standard Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Motor Lead Exit
Ko Box
Motor Lead Quantity/Wire Size
12 @ 10 AWG
Motor Lead Termination
Flying Leads
Motor Letter Type
Three Phase
Motor Standards
NEMA
Motor Type
4052M
Mounting Arrangement
F1
Number of Poles
4
Output
25.000 hp @ 50 Hz, 30.000 hp @ 60 Hz
Output @ Frequency
30.000 HP @ 60 HZ, 25.000 HP @ 50 HZ
Overall Length
29.25 IN
Phase
3
Power Factor
84
Pulley End Bearing Type
Ball
Pulley Face Code
C-Face
Pulley Shaft Indicator
Tapped & Key
Rodent Screen
Included
Service Factor
1.15
Shaft Diameter
1.750 IN
Shaft Extension Location
Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator
Shaft Slinger
Speed
1470 rpm, 1770 rpm
Speed Code
Single Speed
Starting Method
Wye Start - Delta Run
Synchronous Speed
1,800 rpm
Synchronous Speed @ Frequency
1800 RPM @ 60 HZ
Thermal Device - Bearing
None
Thermal Device - Winding
None
Vibration Sensor Indicator
No Vibration Sensor
Voltage
190 V @ 50 Hz, 380 V @ 50 Hz, 230 V @ 60 Hz, 460 V @ 60 Hz
Voltage @ Frequency
230.0 V @ 60 HZ, 190.0 V @ 50 HZ, 460.0 V @ 60 HZ, 380.0 V @ 50 HZ
Winding Thermal 1
None
Winding Thermal 2
None
