Baldor L3506-50 - .75/.55KW, 2850RPM, 1 Phase, 50HZ, TEFC, 3520LC, 5 50HZ Single Phase Single Phase

Save $202.25
BaldorSKU: L3506-50

Price:
Sale price$606.75 Regular price$809.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance Single Phase Enclosed Motor - Model L3506-50

Discover the reliability and efficiency of the Baldor L3506-50 motor, designed for optimal performance in various applications. This single-phase enclosed motor operates at .75/.55KW with a speed of 2850 RPM, making it an ideal choice for your pumping needs. With a frequency of 50HZ and a Totally Enclosed Fan Cooled (TEFC) design, this motor ensures durability and protection against environmental factors.

Key Features:

  • Power: .75/.55KW
  • Speed: 2850 RPM
  • Phase: 1 Phase
  • Frequency: 50HZ
  • Design: TEFC (Totally Enclosed Fan Cooled)
  • Product Code: L3506-50

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor L3506-50 to ensure compatibility. If you encounter any difficulties, our team is here to help you find the perfect solution.

UPC 781568119686
Supplier Part Number L3506-50
Category AC Motors
Subcategory Single Phase Enclosed
Product Family General Purpose
Agency Approvals CE, CURUS, UKCA, WEEE
Ambient Temperature 40 °C
Approximate Weight (lbs) 35.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number L3506-50
Current @ Voltage 7.200 A @ 110.0 V, 3.600 A @ 220.0 V
Design Code -
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 74.1 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEFC
Feedback Device NO FEEDBACK
Frame 56
Frame Material Steel
Frequency 50.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 3.6 a
Insulation Class B
Inverter Code Not Inverter
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Finish CLEAR COAT
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Cap Run
Motor Standards NEMA
Motor Type 3520LC
Mounting Arrangement F1
Number of Poles 2
Output 0.550 kW
Output @ Frequency .550 KW @ 50 HZ
Overall Length 13.23 IN
Phase 1
Power Factor 95
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS NON-COMPLIANT
Service Factor 1.25
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 2850 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 3,000 rpm
Synchronous Speed @ Frequency 3000 RPM @ 50 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 220 V, 110 V
Voltage @ Frequency 110.0 V @ 50 HZ, 220.0 V @ 50 HZ
Winding Thermal 1 None
Winding Thermal 2 None
