Baldor L1508T-50 - 5/3.7KW, 1450RPM, 1 Phase, 50HZ, 213T, 3740LC, O50HZ Single Phase Single Phase

Save $647.25
BaldorSKU: L1508T-50

Price:
Sale price$1,941.75 Regular price$2,589.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance L1508T-50 Single Phase Open Motor

The Baldor-Reliance L1508T-50 is a high-performance single phase open motor designed for reliable operation in various applications. With a power output of 5/3.7KW and a speed of 1450 RPM, this motor is ideal for those seeking efficiency and durability. Operating at 50HZ, it features a 213T frame size and is part of the 3740LC series, ensuring compatibility with a wide range of equipment.

Key Specifications:

  • Power: 5/3.7KW
  • Speed: 1450 RPM
  • Phase: Single Phase
  • Frequency: 50HZ
  • Frame Size: 213T
  • Product Code: L1508T-50

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor L1508T-50 to ensure compatibility. If you encounter any difficulties, our team is here to help you find the right item.

UPC 781568119938
Supplier Part Number L1508T-50
Category AC Motors
Subcategory Single Phase Open
Product Family General Purpose
Agency Approvals CURUS, UKCA, WEEE, CE, C UR US
Ambient Temperature 40 °C
Approximate Weight (lbs) 112.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number L1508T-50
Current @ Voltage 20.400 A @ 220.0 V
Design Code -
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 86.3 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure OPSB
Feedback Device NO FEEDBACK
Frame 213T
Frame Material Steel
Frequency 50.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 20.4 a
Insulation Class F
Inverter Code Not Inverter
KVA Code G
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 2 @ 12 AWG, A PH
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Cap Run
Motor Standards NEMA
Motor Type 3740LC
Mounting Arrangement F1
Number of Poles 4
Output 3.700 kW
Output @ Frequency 3.700 KW @ 50 HZ
Overall Length 18.20 IN
Phase 1
Power Factor 96
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1
Shaft Diameter 1.375 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1450 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,500 rpm
Synchronous Speed @ Frequency 1500 RPM @ 50 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 220 V
Voltage @ Frequency 220.0 V @ 50 HZ
Winding Thermal 1 None
Winding Thermal 2 None

Motor Curves
