Baldor KL1200 - .17 HP, 1725RPM, 1 Phase, 60HZ, 56C, 3408L, Open, F1 60HZ Single Phase Single Phase 17 HP 56°C

Save $132.50
BaldorSKU: KL1200

Price:
Sale price$397.50 Regular price$530.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor KL1200 - Reliable Single Phase Open Motor

The Baldor KL1200 is a high-performance single phase open motor designed for various applications requiring reliable power and efficiency. With a power output of .17 HP and a speed of 1725 RPM, this motor is perfect for driving pumps and other machinery in residential and light commercial settings.

Specifications:

  • Power: .17 HP
  • Speed: 1725 RPM
  • Phase: 1 Phase
  • Frequency: 60 Hz
  • Frame Size: 56C
  • Open Design: Yes
  • Product Code: KL1200

As a trusted vendor, Baldor ensures that the KL1200 motor meets high standards of quality and durability, making it an excellent choice for your pumping needs. At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905.

Before purchasing, we recommend checking your current pump for the exact part number or SKU that matches the Baldor KL1200. If you encounter any difficulties in finding the right item, don’t hesitate to reach out to our knowledgeable team for support.

UPC 781568110683
Supplier Part Number KL1200
Category AC Motors
Subcategory Single Phase Open
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 19.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number KL1200
Current @ Voltage 1.900 A @ 230.0 V, 2.300 A @ 208.0 V, 3.800 A @ 115.0 V
Design Code N
Drip Cover Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 49.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure ODP
Feedback Device NO FEEDBACK
Frame 56C
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Drip Cover Mounting
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 1.9 a
Insulation Class B
Inverter Code Not Inverter
KVA Code M
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3408L
Mounting Arrangement F1
Number of Poles 4
Output 0.170 hp
Output @ Frequency .170 HP @ 60 HZ
Overall Length 11.22 IN
Phase 1
Power Factor 57
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.35
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 115 V
Voltage @ Frequency 115.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
