Baldor JM3112 - .75 HP, 1725RPM, 3 Phase, 60HZ, 56J, 3420M, Open, F1 60HZ Three Phase 75 HP 3420 M Cable

Save $183.50
BaldorSKU: JM3112

Price:
Sale price$550.50 Regular price$734.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance 56J Jet Pump Motor - Model JM3112

Upgrade your pumping system with the Baldor-Reliance 56J Jet Pump Motor, featuring a robust .75 HP power output and a reliable 1725 RPM speed. This three-phase motor operates at 60HZ, making it an ideal choice for various applications requiring efficient and consistent performance.

Designed for durability and efficiency, the Baldor JM3112 is an open-type motor with a 56J frame and a 3420M insulation class, ensuring it can withstand demanding environments. Whether you're replacing an old motor or upgrading your system, this motor is engineered to deliver optimal performance.

At Pump-Stop.com, we are your preferred source for replacement pumps and parts. If you have questions or need assistance finding the right pump for your application, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the Baldor JM3112 to ensure compatibility. If you’re having trouble locating the right item, our team is here to help!

Key Features:

  • Power: .75 HP
  • Speed: 1725 RPM
  • Phase: 3 Phase
  • Frequency: 60HZ
  • Frame: 56J
  • Insulation Class: 3420M
  • Type: Open

Choose the Baldor-Reliance 56J Jet Pump Motor for reliable performance and efficiency in your pumping applications.

UPC 781568218341
Supplier Part Number JM3112
Category AC Motors
Subcategory 56J Jet Pump Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 27.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number JM3112
Current @ Voltage 1.500 A @ 460.0 V, 3.000 A @ 230.0 V, 3.200 A @ 208.0 V
Design Code B
Drip Cover Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 75.5 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure ODP
Feedback Device NO FEEDBACK
Frame 56J
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Drip Cover Mounting
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 1.5 a
Insulation Class B
Inverter Code Not Inverter
KVA Code M
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3420M
Mounting Arrangement F1
Number of Poles 4
Output 0.750 hp
Output @ Frequency .750 HP @ 60 HZ
Overall Length 12.34 IN
Phase 3
Power Factor 64
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Ext Thread
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.25
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 208 V, 230 V, 460 V
Voltage @ Frequency 208.0 V @ 60 HZ, 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
