Baldor JL1301A - .33 HP, 1725RPM, 1 Phase, 60HZ, 56J, 3414L, Open, F1 60HZ Single Phase 33 HP

Save $138.00
BaldorSKU: JL1301A

Price:
Sale price$414.00 Regular price$552.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance 56J Jet Pump Motor - Model JL1301A

Upgrade your pumping system with the Baldor-Reliance 56J Jet Pump Motor, designed for reliable performance and efficiency. This motor features a power output of .33 HP and operates at 1725 RPM, making it ideal for various applications requiring a robust and dependable motor.

Key specifications include:

  • Phase: 1 Phase
  • Frequency: 60HZ
  • Frame Size: 56J
  • Open Drip Proof Design: Yes
  • Product Code: JL1301A

This motor is perfect for those looking to replace or upgrade their existing pump systems. At Pump-Stop.com, we are your preferred source for replacement pumps and parts, ensuring you find the right fit for your needs. If you have questions or need assistance, feel free to call us at (781) 281-8905.

Before purchasing, we recommend checking your current pump for the exact part number or SKU to ensure compatibility. If you’re having trouble finding the right item, our knowledgeable team is here to help!

UPC 781568217870
Supplier Part Number JL1301A
Category AC Motors
Subcategory 56J Jet Pump Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 23.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator No Mounting
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number JL1301A
Current @ Voltage 6.000 A @ 115.0 V, 3.600 A @ 208.0 V, 3.000 A @ 230.0 V
Design Code N
Drip Cover Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 60.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure ODP
Feedback Device NO FEEDBACK
Frame 56J
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Terminal Panel
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 3.0 a
Insulation Class B
Inverter Code Not Inverter
IP Rating NONE
KVA Code L
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Terminal Panel Or Lead Hole
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3414L
Mounting Arrangement F1
Number of Poles 4
Output 0.330 hp
Output @ Frequency .330 HP @ 60 HZ
Overall Length 11.89 IN
Phase 1
Power Factor 60
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Ext Thread
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.35
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Fixed Opposite Standard
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 115 V
Voltage @ Frequency 230.0 V @ 60 HZ, 115.0 V @ 60 HZ
Winding Thermal 1 Automatic Thermal Overload
Winding Thermal 1 Location SB
Winding Thermal 2 None

Motor Curves
