Baldor FPM2549T-2/4 - 75 HP, 3535RPM, 3 Phase, 60HZ, 364TS, 4250M, Opsb, F 60HZ Three Phase 75 HP 4250 M Cable

Save $2,444.50
BaldorSKU: FPM2549T-2/4

Price:
Sale price$7,333.50 Regular price$9,778.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance Fire Pump - Model FPM2549T-2/4

Introducing the Baldor-Reliance Fire Pump, a high-performance solution designed for demanding applications. This robust fire pump features a powerful 75 HP motor, operating at 3535 RPM, and is engineered for 3-phase power at 60Hz. With a frame size of 364TS and a durable construction rated at 4250M, this pump is built to deliver reliable performance in critical situations.

As a trusted provider of pumps and parts, Pump-Stop.com is your preferred source for replacement pumps and components. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905.

Before purchasing, we recommend checking your current pump for the exact part number or SKU that matches the Baldor FPM2549T-2/4. If you encounter any difficulties in locating the right item, our knowledgeable team is here to help!

Key Features:

  • 75 HP motor for powerful performance
  • Operating speed of 3535 RPM
  • 3-phase, 60Hz operation
  • Durable 364TS frame size
  • Rated at 4250M for reliability

Ensure your fire protection system is equipped with the best. Choose the Baldor-Reliance Fire Pump for unmatched quality and performance.

UPC 781568816851
Supplier Part Number FPM2549T-2/4
Category AC Motors
Subcategory Fire Pump
Product Family Fire Pump Motor
Agency Approvals CULUS, CSA EEV
Ambient Temperature 40 °C
Approximate Weight (lbs) 485.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number FPM2549T-2/4
Current @ Voltage 192.000 A @ 200.0 V, 96.000 A @ 400.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 93.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure ODP
Feedback Device NO FEEDBACK
Frame 364TS
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No Heater
High Voltage Full Load Amps 96.0 a
Insulation Class F
Inverter Code Not Inverter
KVA Code F
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 12 @ 6 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 4250M
Mounting Arrangement F1
Number of Poles 2
Output 75.000 hp
Output @ Frequency 75.000 HP @ 60 HZ
Overall Length 25.82 IN
Phase 3
Power Factor 90
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 1.875 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 3535 rpm
Speed Code Single Speed
Starting Method Wye Start - Delta Run
Synchronous Speed 3,600 rpm
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 200 V, 400 V
Voltage @ Frequency 200.0 V @ 60 HZ, 400.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
