UPC
781568463932
Supplier Part Number
ECP63774TR-4
Category
AC Motors
Subcategory
661XL Motors
Product Family
Chem Process S/P 32-8 IEEE 841
Agency Approvals
NEMA_PREMIUM, UR, CSA EEV, CCSA US
Ambient Temperature
40 °C
Approximate Weight (lbs)
231.0
Auxillary Box
No Auxillary Box
Auxillary Box Lead Termination
None
Base Indicator
Rigid
Bearing Grease Type
MOBIL SHC POLYREX 222
Blower
None
Catalog Number
ECP63774TR-4
Constant Torque Speed Range
1.3
Current @ Voltage
12.500 A @ 460.0 V
Design Code
B
Drip Cover
No Drip Cover
Duty Rating
CONT
Efficiency @ 100% Load
91.7 %
Electrically Isolated Bearing
Not Electrically Isolated
Enclosure
TEFC
Enclosure Modification
841
Feedback Device
NO FEEDBACK
Frame
215T
Frame Material
Cast Iron
Frequency
60.00 Hz
Front Face Code
C-Face
Front Shaft Indicator
None
Haz Area Class and Group
Class I, Group A,B,C & D
Haz Area Division
Division II
Haz Area Temp Code
T3C
Heater Indicator
No Heater
High Voltage Full Load Amps
12.5 a
Insulation Class
F
Inverter Code
Inverter Duty
KVA Code
H
Lifting Lugs
Standard Lifting Lugs
Locked Bearing Indicator
Locked Bearing
Max Speed
2700 rpm
Motor Lead Exit
Ko Box
Motor Lead Quantity/Wire Size
3 @ 14 AWG
Motor Lead Termination
Flying Leads
Motor Letter Type
Three Phase
Motor Standards
NEMA
Motor Type
0748M
Mounting Arrangement
F1
Number of Poles
4
Output
10.000 hp
Output @ Frequency
10.000 HP @ 60 HZ
Overall Length
19.49 IN
Phase
3
Power Factor
81
Pulley End Bearing Type
Roller
Pulley Face Code
Standard
Pulley Shaft Indicator
Standard
Rodent Screen
None
RoHS Status
ROHS COMPLIANT
Service Factor
1.15
Shaft Diameter
1.375 IN
Shaft Extension Location
Pulley End
Shaft Ground Indicator
No Shaft Grounding
Shaft Rotation
Reversible
Shaft Slinger Indicator
Shaft Slinger
Speed
1765 rpm
Speed Code
Single Speed
Starting Method
Direct on line
Synchronous Speed
1,800 rpm
Synchronous Speed @ Frequency
1800 RPM @ 60 HZ
Thermal Device - Bearing
None
Thermal Device - Winding
None
Vibration Sensor Indicator
No Vibration Sensor
Voltage
460 V
Voltage @ Frequency
460.0 V @ 60 HZ
Winding Thermal 1
None
Winding Thermal 2
None
