Baldor CSPM3311T - 7.5 HP, 1775RPM, 3 Phase, 60HZ, 213TC, 3750M, Opsb 60HZ Three Phase Three Phase 7.5 HP 3750 M Cable

Save $1,089.20
BaldorSKU: CSPM3311T

Price:
Sale price$1,633.80 Regular price$2,723.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance CSPM3311T - 7.5 HP Three Phase Motor

Introducing the Baldor-Reliance CSPM3311T, a high-performance 7.5 HP, 1775 RPM three-phase motor designed for reliability and efficiency in various industrial applications. This motor operates at 60HZ and features a 213TC frame size, making it an ideal choice for those seeking robust performance in demanding environments.

Key Features:

  • Power: 7.5 HP
  • Speed: 1775 RPM
  • Phase: 3 Phase
  • Frequency: 60HZ
  • Frame Size: 213TC
  • Enclosure Type: SP4 Three Phase Enclosed
  • Product Code: CSPM3311T

At Pump-Stop, we pride ourselves on being the preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please don't hesitate to call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU that matches the CSPM3311T to ensure compatibility. Our team is here to help you find the perfect solution for your needs.

UPC 781568597972
Supplier Part Number CSPM3311T
Category AC Motors
Subcategory SP4 Three Phase Enclosed
Product Family General Purpose
Agency Approvals CURUSEEV, NEMA PREMIUM, WEEE
Ambient Temperature 40 °C
Approximate Weight (lbs) 158.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CSPM3311T
Current @ Voltage 10.000 A @ 460.0 V, 20.000 A @ 230.0 V
Design Code A
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 92.4 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure OPSB
Feedback Device NO FEEDBACK
Frame 213TC
Frame Material Steel
Frequency 60.00 Hz
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 10.0 a
Insulation Class F
Inverter Code Inverter Duty
KVA Code L
Lifting Lugs Standard Lifting Lugs
Locked Bearing Indicator Locked Bearing
Max Speed 2700 rpm
Motor Lead Quantity/Wire Size 9 @ 14 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3750M
Mounting Arrangement F1
Number of Poles 4
Output 7.500 hp
Output @ Frequency 7.500 HP @ 60 HZ
Overall Length 18.94 IN
Phase 3
Power Factor 78
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.15
Shaft Diameter 1.375 IN
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1775 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 460 V
Voltage @ Frequency 460.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
