Baldor CJM3107 - .5 HP, 3450RPM, 3 Phase, 60HZ, 56J, 3413M, Open, F1 60HZ Three Phase 5 HP 3413 M Cable

Save $231.20
BaldorSKU: CJM3107

Price:
Sale price$346.80 Regular price$578.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor-Reliance 56J Jet Pump Motor - Model CJM3107

Upgrade your pumping system with the Baldor CJM3107 Jet Pump Motor. This high-performance motor features a robust 0.5 HP power output and operates at 3450 RPM, making it ideal for a variety of applications. Designed for 3-phase operation at 60Hz, this motor is built to deliver reliable performance and efficiency.

Key specifications include:

  • Power: 0.5 HP
  • Speed: 3450 RPM
  • Phase: 3
  • Frequency: 60Hz
  • Frame: 56J
  • Open design for optimal cooling
  • Product Code: CJM3107

As the preferred source for replacement pumps and parts, Pump-Stop.com is here to help you find the right motor for your needs. If you have questions or need assistance locating the correct part, please call us at (781) 281-8905. We recommend checking your current pump for the exact part number or SKU to ensure compatibility.

Choose the Baldor-Reliance 56J Jet Pump Motor for dependable performance and efficiency in your pumping applications.

UPC 781568113134
Supplier Part Number CJM3107
Category AC Motors
Subcategory 56J Jet Pump Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 22.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CJM3107
Current @ Voltage 1.200 A @ 460.0 V, 2.400 A @ 230.0 V, 3.100 A @ 208.0 V
Design Code B
Drip Cover Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 70.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure ODP
Feedback Device NO FEEDBACK
Frame 56J
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Drip Cover Mounting
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 1.2 a
Insulation Class B
Inverter Code Not Inverter
KVA Code N
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3413M
Mounting Arrangement F1
Number of Poles 2
Output 0.500 hp
Output @ Frequency .500 HP @ 60 HZ
Overall Length 11.72 IN
Phase 3
Power Factor 65
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Ext Thread
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.6
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 3450 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 3,600 rpm
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 460 V
Voltage @ Frequency 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
