Baldor CHC3504A - .5 HP, 1700RPM, 1 Phase, 60HZ, 56, 3420C, Teao, F1, N 60HZ Single Phase 5 HP 3420°C

Save $319.60
BaldorSKU: CHC3504A

Price:
Sale price$479.40 Regular price$799.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor CHC3504A General Purpose HVAC Motor

Upgrade your HVAC system with the Baldor CHC3504A, a reliable and efficient .5 HP motor designed for general purpose applications. Operating at 1700 RPM and powered by a single-phase 60Hz supply, this motor is perfect for various heating, ventilation, and air conditioning needs.

Specifications:

  • Power: .5 HP
  • Speed: 1700 RPM
  • Phase: 1
  • Frequency: 60Hz
  • Frame Size: 56
  • Temperature Class: 3420C
  • Enclosure Type: TEAO (Totally Enclosed Air Over)
  • Mounting: F1
  • Product Code: CHC3504A

This Baldor-Reliance motor is engineered for durability and performance, making it an ideal choice for both residential and commercial HVAC systems. At Pump-Stop, we are your preferred source for replacement pumps and parts, ensuring you find the right solution for your needs.

Before purchasing, please check your current pump for the exact part number or SKU that matches the Baldor CHC3504A. If you have any questions or need assistance in finding the right item, feel free to call us at (781) 281-8905. Our team is here to help you with all your HVAC motor needs!

UPC 781568849712
Supplier Part Number CHC3504A
Category AC Motors
Subcategory General Purpose HVAC Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 25.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Resilient
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number CHC3504A
Current @ Voltage 2.600 A @ 230.0 V, 2.800 A @ 208.0 V, 5.200 A @ 115.0 V
Design Code -
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 72.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEAO
Feedback Device NO FEEDBACK
Frame 56
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Resilient Mount
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 2.6 a
Insulation Class B
Inverter Code Not Inverter
KVA Code H
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Terminal Panel
Motor Lead Quantity/Wire Size 7 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Oil Capacitor Start and Run
Motor Standards NEMA
Motor Type 3420C
Mounting Arrangement F1
Number of Poles 4
Output 0.500 hp
Output @ Frequency .500 HP @ 60 HZ
Overall Length 11.59 IN
Phase 1
Power Factor 86
Pulley End Bearing Type Ball
Pulley Face Code Resilient Mount
Pulley Shaft Indicator Standard
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1.15
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible: Connected Standard
Shaft Slinger Indicator No Slinger
Speed 1700 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 230 V, 115 V
Voltage @ Frequency 115.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 Automatic Thermal Overload
Winding Thermal 1 Location EP
Winding Thermal 2 None
