Baldor AOM3546T - 1 HP, 1725RPM, 3 Phase, 60HZ, 143T, 3428M, Teao, F1 60HZ Three Phase 1 HP 3428 M Cable

Save $326.00
BaldorSKU: AOM3546T

Price:
Sale price$489.00 Regular price$815.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor AOM3546T - 1 HP Yoke/Pedestal Fan Motor

Upgrade your ventilation system with the Baldor AOM3546T, a high-performance 1 HP Yoke/Pedestal Fan Motor designed for efficiency and reliability. Operating at 1725 RPM and powered by a robust 3-phase, 60Hz electrical supply, this motor is ideal for various industrial and commercial applications.

  • Power: 1 HP
  • Speed: 1725 RPM
  • Phase: 3 Phase
  • Frequency: 60 Hz
  • Frame Size: 143T
  • Enclosure Type: TEAO (Totally Enclosed Air Over)
  • Product Code: AOM3546T

This Baldor-Reliance motor is engineered for durability and optimal performance, making it a perfect choice for yoke and pedestal fan applications. At Pump-Stop.com, we are your preferred source for replacement pumps and parts, ensuring you find the right components for your needs.

Before purchasing, please check your current pump for the exact part number or SKU that matches the Baldor AOM3546T. If you have any questions or need assistance in finding the right item, feel free to call us at (781) 281-8905. Our team is here to help you with all your pump and motor needs!

UPC 781568121689
Supplier Part Number AOM3546T
Category AC Motors
Subcategory Yoke/Pedestal Fan Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 33.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number AOM3546T
Current @ Voltage 1.800 A @ 460.0 V, 3.600 A @ 230.0 V, 3.800 A @ 208.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 75.5 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEAO
Feedback Device NO FEEDBACK
Frame 143T
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Standard
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 1.8 a
Insulation Class B
Inverter Code Not Inverter
KVA Code L
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Quantity/Wire Size 9 @ 18 AWG
Motor Lead Termination Flying Leads
Motor Letter Type Three Phase
Motor Standards NEMA
Motor Type 3428M
Mounting Arrangement F1
Number of Poles 4
Output 1.000 hp
Output @ Frequency 1.000 HP @ 60 HZ
Overall Length 11.81 IN
Phase 3
Power Factor 64
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Standard
Rodent Screen None
Service Factor 1.15
Shaft Diameter 0.875 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 1725 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 1,800 rpm
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 208 V, 230 V, 460 V
Voltage @ Frequency 208.0 V @ 60 HZ, 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
Winding Thermal 1 None
Winding Thermal 2 None
