Baldor AFL3523A - 2 HP, 3450RPM, 1 Phase, 60HZ, 143TZ, 3535L, Teao, F1 60HZ Single Phase 2 HP

Save $523.60
BaldorSKU: AFL3523A

Price:
Sale price$785.40 Regular price$1,309.00
Delivery date to be confirmed on Sales Order
or Call for most up to date lead times. (781) 281-8905

Description

Baldor AFL3523A - 2 HP Application Specific Motor

The Baldor AFL3523A is a high-performance application-specific motor designed to meet the demanding needs of various industrial applications. With a robust 2 HP power output and a speed of 3450 RPM, this single-phase motor operates efficiently at 60Hz, making it an ideal choice for pump systems and other machinery.

Key Features:

  • Power: 2 HP
  • Speed: 3450 RPM
  • Phase: 1 Phase
  • Frequency: 60Hz
  • Frame Size: 143TZ
  • Enclosure Type: TEAO (Totally Enclosed Air Over)
  • Product Code: AFL3523A

This Baldor-Reliance motor is engineered for durability and reliability, making it a preferred choice for those seeking quality and performance in their applications. At Pump-Stop, we pride ourselves on being the preferred source for replacement pumps and parts. If you have questions or need assistance in finding the right pump for your application, please call us at (781) 281-8905.

Before purchasing, we recommend checking your current pump for the exact part number or SKU that matches the Baldor AFL3523A. If you encounter any difficulties in locating the right item, our knowledgeable team is here to help!

UPC 781568121320
Supplier Part Number AFL3523A
Category AC Motors
Subcategory Application Specific Motors
Product Family General Purpose
Agency Approvals CURUS
Ambient Temperature 40 °C
Approximate Weight (lbs) 51.0
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Catalog Number AFL3523A
Current @ Voltage 11.500 A @ 230.0 V, 23.000 A @ 115.0 V
Design Code L
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 74.0 %
Electrically Isolated Bearing Not Electrically Isolated
Enclosure TEAO
Feedback Device NO FEEDBACK
Frame 143TZ
Frame Material Steel
Frequency 60.00 Hz
Front Face Code Terminal Panel
Front Shaft Indicator None
Haz Area Class and Group NONE
Haz Area Division Not Applicable
Heater Indicator No Heater
High Voltage Full Load Amps 11.5 a
Insulation Class B
Inverter Code Not Inverter
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Terminal Panel Or Lead Hole
Motor Lead Quantity/Wire Size 4 @ 14 AWG, A&J
Motor Lead Termination Flying Leads
Motor Letter Type Cap Start, Induction Run
Motor Standards NEMA
Motor Type 3535L
Mounting Arrangement F1
Number of Poles 2
Output 2.000 hp
Output @ Frequency 2.000 HP @ 60 HZ
Overall Length 13.61 IN
Phase 1
Power Factor 82
Product Type FARM DUTY
Pulley End Bearing Type Ball
Pulley Face Code Standard
Pulley Shaft Indicator Tapped & Key
Rodent Screen None
RoHS Status ROHS COMPLIANT
Service Factor 1
Shaft Diameter 0.875 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible: Connected Standard
Shaft Slinger Indicator No Slinger
Speed 3450 rpm
Speed Code Single Speed
Starting Method Direct on line
Synchronous Speed 3,600 rpm
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Thermal Device - Bearing None
Thermal Device - Winding None
Vibration Sensor Indicator No Vibration Sensor
Voltage 115 V, 230 V
Voltage @ Frequency 115.0 V @ 60 HZ, 230.0 V @ 60 HZ
Winding Thermal 1 Automatic Thermal Overload
Winding Thermal 1 Location SB
Winding Thermal 2 None
