Grundfos 91836408 DMX 199-8 AR-SS/V/SS-S-H1A3A3B Mechanical Diaphragm Chemical Metering Pump

This item ships free!
GrundfosSKU: 91836408

Contact for price
or Call for most up to date lead times. (781) 281-8905

Description

⚠ Discontinued Product This model has been discontinued by Grundfos. Stock may be limited. Contact PumpStop to confirm availability or find a replacement model.
Grundfos — World's Largest Pump Manufacturer · Bjerringbro, Denmark
DMX 199-8 AR-SS/V/SS-S-H1A3A3B · Mechanical dosing pumps
DMX 199-8115 V, 60 HzV1-Phase60 HzIP 65/F

The Grundfos 91836408 (DMX 199-8 AR-SS/V/SS-S-H1A3A3B) is a Mechanical dosing pumps 115 V, 60 HzV 1-Phase — Diaphragm dosing pumps with external motor. Designed for Plumbing: Water Disinfection, Process liquids transfer, Cooling and 1 more.

Voltage
115 V, 60 HzV
Phase
1-Phase
Frequency
60 Hz
Max Pressure
116.03psi
Grundfos
World's largest pump manufacturer — engineering and manufacturing in 17 countries since 1945
Industrial Grade
Built and tested to IEC and NEMA standards
Authorized Distributor
Genuine Grundfos product — full manufacturer warranty coverage
Expert Support
Technical help available — call (781) 281-8905 or chat
gf-sh"
Why This Product

Genuine Grundfos Parts and Accessories

Genuine Grundfos replacement parts and accessories are manufactured to the same specifications as the original components — ensuring correct fit, correct function, and maintenance of original pump performance.

OEM Quality — Maintains Warranty Coverage

Using genuine Grundfos replacement parts maintains pump warranty coverage where applicable. Third-party parts may void warranty coverage and can cause performance changes and premature failure.

Compatibility Confirmed

Grundfos accessories and replacement parts are tested for compatibility with specific Grundfos pump models. Part numbers are model-specific — always verify using your pump's model number and serial number.

PumpStop Expert Support

Not sure if this is the right part for your pump? Contact PumpStop with your pump model number and serial number — our team will confirm compatibility before you order.

Model Code Decoded — DMX 199-8 AR-SS/V/SS-S-H1A3A3B
Series: DMX 199-8
Model Code: DMX 199-8 AR-SS/V/SS-S-H1A3A3B
Performance
Max Operating Pressure 116.03psi
Electrical Specifications
Voltage 115 V, 60 HzV
Phase 1-Phase
Frequency 60 Hz
Protection Class (IP) IP 65/F
Cable / Plug Type USA, Canada
Connections
Inlet Connection 3/4inch
Outlet Connection 3/4inch
Materials
Product Identity
Model Number 91836408
Product Series DMX 199-8
Model Code DMX 199-8 AR-SS/V/SS-S-H1A3A3B
Approvals / Certifications CE
Applications
Plumbing: Water Disinfection
Process liquids transfer
Cooling
Industrial process water treatment
Important Notices
Electrical Requires correctly rated supply — 115 V, 60 HzV, 1-Phase, 60 Hz. Install with correctly rated circuit protection and motor starter.
Temperature limits Do not exceed max fluid temperature per nameplate. Operating outside these limits will damage seals and motor insulation.
Dry running Do not run dry. DMX 199-8 pumps use the pumped fluid to lubricate the shaft seal — dry running destroys the seal within seconds. Install dry-run protection on all automatic installations.
Maintenance Refer to the Grundfos Installation and Operating Manual (IOM) for correct installation, commissioning, and maintenance intervals. Contact PumpStop for documentation.
Documentation
✓ Installation and Operating Manual (IOM) — DMX 199-8
✓ Product Data Sheet — DMX 199-8 AR-SS/V/SS-S-H1A3A3B
✓ Service Manual and Spare Parts List
Need the IOM, data sheet, or spare parts list? Contact PumpStop and we'll send it over.
Before You OrderConfirm model code, voltage, phase, and frequency match your installation requirements. For sizing help or spare parts guidance, chat or call (781) 281-8905.
EAN 5700835249890
Applications Chemical Metering, Cooling Tower, Food & Beverage Services, Industrial Processes, Municipal Drinking Water, Pulp & Paper, Textile Industry, Wastewater Treatment, Water Treatment
