Description
Lutz Pumpen GmbH — Drum Pump Specialists since 1954 · Wertheim, Germany
Part 0372-502 · Dispensing Nozzle · Zapfpistole Messing
The Lutz 0372-502 is a Dispensing Nozzle with Messing housing. Delivers up to 80 l/min.
Max Flow
80 l/min
Max Temp
80°C
Type
Dispensing Nozzl
German Engineering
Manufactured in Wertheim, Germany to IEC and EU standards since 1954
Chemical-Grade Materials
Wetted materials selected for chemical compatibility — Messing
ATEX Certified
Explosion protection: Ja
Expert Support
Technical help available — call (781) 281-8905 or chat
Why This Product
Lutz Pumpen GmbH — German Engineering since 1954
Lutz Pumpen GmbH has manufactured drum pumps, pump tubes, and liquid transfer equipment in Wertheim, Germany since 1954. Products are manufactured to IEC, ATEX, and EU standards with independent third-party certification.
Chemical Compatibility — Verify Before Use
For all Lutz products in chemical service, verify material compatibility with your specific fluid, concentration, and temperature before installation. Lutz provides detailed chemical resistance data — contact PumpStop for guidance.
Technical Specifications
| Part Number | 0372-502 |
| Product Type | Dispensing Nozzle |
| Product Name | Zapfpistole Messing |
| Explosion Protection | Ja |
| Housing Material | Messing |
| Max Flow Rate | 80 l/min |
| Max Operating Pressure | 4 bar |
| Max Fluid Temperature | 80°C |
| Max Viscosity | 760 mPas |
| Discharge Thread | 1 1/4" |
| Type / Model Code | Zapfpistole Messing |
Important Notices
| Chemical compatibility | Always verify pump tube, impeller, and seal materials are compatible with your specific fluid, concentration, and temperature before installation. |
| Electrical safety | Connect only to the specified supply voltage. Protect motor with correctly rated overcurrent protection. |
| Explosion protection | This product carries ATEX explosion protection: Ja. Use only in the area classification for which it is rated. |
| Drum fit | Ensure the drum bung opening is compatible with the pump tube diameter before installation. The pump tube must not exceed the bung opening to ensure a leak-free, gas-tight connection. |
Documentation
✓ Product Specification Sheet — Zapfpistole Messing
✓ Chemical Resistance Guide — Lutz Pump Materials
✓ ATEX Certificate — Ja
Need the spec sheet, chemical resistance data, or ATEX certificate? Contact PumpStop and we'll send it over.
Before You OrderVerify pump tube material compatibility with your specific fluid, concentration, and temperature. For configuration guidance, chat or call (781) 281-8905.
