Description
The Lutz 0174-548 is a Eccentric Screw Pump with a Stainless Steel (1.4404) pump tube, druckluft, elektro-driven. Delivers up to 50 l/min at up to 8 bar.
Eccentric Screw Technology — Viscous Fluid Specialist
Progressive cavity (eccentric screw) design transfers viscous, shear-sensitive, and structured fluids that centrifugal impellers would damage — creams, pastes, gels, adhesives, and high-viscosity chemicals.
Low Shear — Preserves Fluid Structure
Gentle, pulsation-free pumping action preserves the physical structure of shear-sensitive fluids. Recommended for polymer solutions, cosmetics, pharmaceutical products, and food-grade viscous materials.
PURE and SanitaryPlus Versions
SanitaryPlus versions meet hygienic design requirements for pharmaceutical and food applications. PURE versions use no metal wetted components for highest-purity chemical service.
Wide Viscosity Range
Handles fluids from thin liquids to high-viscosity pastes — a single pump covers a viscosity range that would require multiple pump types in a conventional centrifugal installation.
| Part Number | 0174-548 |
| Product Type | Eccentric Screw Pump |
| Product Name | Exzenterschneckenpumpwerk B70V SanitaryPlus |
| Drive Type | Druckluft, Elektro |
| Certification | 3-A Sanitary Standard |
| Pump Tube Material | Stainless Steel (1.4404) |
| Drive Shaft Material | Stainless Steel 316Ti |
| Rotor Material | Stainless Steel 316Ti |
| Stator Material | EPDM (Ethylen-Propylen-Dien-Kautschuk) |
| Seal Type | Gleitringdichtung (GLRD) |
| Mechanical Seal | SIC, Kohle, EPDM |
| Max Flow Rate | 50 l/min |
| Max Head (bar) | 8 bar |
| Max Fluid Temperature | 100°C |
| Max Viscosity | 30000 mPas |
| Immersion Depth | 1100 mm |
| Max Dip Tube Diameter | 54 mm |
| Type / Model Code | B70V-H-SR Sanitary Plus |
| Chemical compatibility | Always verify pump tube, impeller, and seal materials are compatible with your specific fluid, concentration, and temperature before installation. |
| Electrical safety | Connect only to the specified supply voltage. Protect motor with correctly rated overcurrent protection. |
| Explosion protection | Standard version is not explosion protected. For flammable fluids or hazardous locations, specify an ATEX-rated version. |
| Drum fit | Ensure the drum bung opening is compatible with the pump tube diameter before installation. The pump tube must not exceed the bung opening to ensure a leak-free, gas-tight connection. |
