Description
The Lutz 0162-204 is a Pump Tube Assembly with a HC (Hastelloy C) pump tube. Delivers up to 123 l/min at up to 26 mWS head. Sealless design — no media-contacting shaft seal, no seal wear, no leak risk at the seal interface.
Pump Tube Only — Pair with Your Lutz Motor
This is a pump tube assembly without a motor — designed to connect to a compatible Lutz motor. Verify motor compatibility before ordering. Tube material, diameter, and shaft connection type must match your motor.
Material Is Critical — Select for Your Fluid
Polypropylene for acids and alkalis. Stainless steel for solvents and petroleum products. PVDF for aggressive oxidizers and concentrated acids. Select the tube material based on your specific fluid and concentration.
Sealless Design — No Media-Contacting Seal
No mechanical shaft seal in the fluid path. The impeller runs in the fluid without a seal interface — no seal wear, no replacement intervals, no seal-related leakage over the product lifetime.
Replacement and Material Upgrade
Replacement tubes allow motor reuse when the tube reaches end of life. Also used to upgrade material configuration — replace the tube with a different material while retaining the existing motor and accessories.
| Part Number | 0162-204 |
| Product Type | Pump Tube Assembly |
| Product Name | Pumpwerk HC |
| Explosion Protection | Ja |
| Certification | ATEX Richtlinie (ATEX Richtlinie 2014/34/EU) |
| Pump Tube Material | HC (Hastelloy C) |
| Impeller Material | ETFE |
| Impeller Type | Laufrad (Radiales Förderrad) |
| Drive Shaft Material | Hastelloy C-22 |
| Bearing Material | ETFE / Kohle |
| Seal Type | Sealless (no media-contacting seals) |
| Max Flow Rate | 123 l/min |
| Max Head | 26 mWS |
| Max Fluid Temperature | 120°C |
| Max Fluid Density | 1,9 kg/dm³ |
| Max Viscosity | 750 mPas |
| Immersion Depth | 1000 mm |
| Max Dip Tube Diameter | 42 mm |
| Discharge Thread | 1 1/4" |
| Type / Model Code | HC 42-L-DL Ex |
| Chemical compatibility | Always verify pump tube, impeller, and seal materials are compatible with your specific fluid, concentration, and temperature before installation. |
| Electrical safety | Connect only to the specified supply voltage. Protect motor with correctly rated overcurrent protection. |
| Explosion protection | This product carries ATEX explosion protection: Ja. Use only in the area classification for which it is rated. |
| Drum fit | Ensure the drum bung opening is compatible with the pump tube diameter before installation. The pump tube must not exceed the bung opening to ensure a leak-free, gas-tight connection. |
