Description
CRN 45-3-1 A-G-H-V-HQQV | Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in high-grade stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via ANSI flanges.
EAN
5713835126016
Material Pricing Group
6
Code for rubber
V
Material code
H
Max pressure at stated temp
232 psi / 194 °F
Maximum operating pressure
16 bar
Size of inlet connection
3 inch
Support bearing
Graflon
Type of connection
ANSI
Bearing 1
Graflon
Flange size for motor
284TC
Size of outlet connection
3 inch
Connect code
G
Liquid temperature range
-4 .. 194 °F
Net weight
159.0 lb
Gross weight
177.0 lb
Pressure rating for connection
PN 16
Frequency converter
NONE
Pressure sensor
N
DOE Pump Energy Index CL
0.89
Pump speed on which pump data are based
3521 rpm
Stages
3
Approvals
CE
Rated flow
238 US gpm
Model
B
Version
A
Diameter
5.34 in
Motor
284TC
Rubber
V
Maximum head
341.6 ft
Motor standard
NEMA
Rated head
264.4 ft
Actual impeller diameter
5.34 in
Curve tolerance
ISO9906:2012 3B
Impellers
1
Connection
PN 16
Impeller
Stainless steel
Code for shaft seal
HQQV
Number of reduced-diameter impellers
1
Flange rating inlet
150 lb
Low NPSH
N
Standard
NEMA
Pump version
A
Motor Curves
